Productos >> 2F6 FIR
Código: 980375
- Genera un impulso perfecto
- Mejora la calidad del sonido
|
MONITOREA Y CONTROLA
desde tu PC
 | |
1. | Conecta fácilmente gracias a sus puertos RS485 y Ethernet |
 | |
2. | Ajusta tu sistema de manera simple con el Software F Series ( Descarga dando click aquí ) |
TODO LO QUE NECESITAS
EQ paramétrico | 31 bandas | 16 diferentes tipos de filtro
Para quienes
prefieren lo Clásico
Pendientes de crossover HPF/LPF,
tipo IIR, Butterworth/Linkwitz-Riley/Bessel
de 6dB hasta 48 dB por octava,
ecualizador paramétrico de 8 bandas
PROTEGE
TU EQUIPO
Etapa de amplificación y altavoces
evita distorsión
ADAPTA TU SISTEMA A
CUALQUIER LUGAR
DELAY SALIDA
Ajusta la distancia de los
componentes de tus cajas o
subwoofers.
DELAY ENTRADA
mayor a 200 metros
Manten alineado tu sistema
principal.
TODO PARA UN MEJOR SONIDO
SIN COMPLICACIONES
VIDEOS
GALERÍA
Adquiérelo con nuestro distribuidor
autorizado mas cercano desde:
$9,860.00
DESCARGAS
ESPECIFICACIONES
DSP Processing | ||
Signal generator | white noise/pink noise, level range: -30dBu~+10dBu | |
input & output gain | -18 dB ~ +12 dB, step 0.1dB | |
Noise gate | Threshold range: -80dBu~-45dBu Attack time: 1ms~1000ms; Release time: 1ms~1000ms | |
Dynamic loudness filter | Gain range: 0dB-10dB Attack speed: fast / medium / slow | |
Parametric equalizer | Input channels up to 31 optional types of PEQ output channels up to 8 optional types of PEQ | |
Optional types include | Bell filter, 1st order high Shelf filter, 2nd order high Shelf filter Variable Q high Shelf filter, 1st order low Shelf filter, 2nd order low Shelf filter Variable Q low Shelf filter, 1st-order low-pass filter, 2nd-order low-pass filter Variable Q low pass filter, 1st order high pass filter, 2nd order high pass filter Variable Q high pass filter, band pass filter, notch filter 1st order allpass filter, 2nd order all-pass filter with variable Q value | |
The center frequency | Ajustable rango frecuencia de 20Hz~20kHz con pasos de 1Hz | |
Q value/bandwidth | Q valor Bell filter: 0.4~128, Q valor de high-pass/low-pass filter: 0.1~5.1 Q valor notch filter : 4~104 | |
EQ gain | -15dB～+15dB | |
IIR crossover(Filtros clasicos) | Butterworth slope: 6/12/18/24/36/48dB por octava Bessel slope: 12/24dB por octava Linkwitz-Riley slope: 12/24/36/48dB por octava | |
Linear phase filter | Linkwitz-Riley: 24/48dB por octava, | |
FIR crossover filter | High pass/low pass/band pass/external import Taps range: 256 ~ 512,slope range 21 ~ 120dB por octava Time window type: Rect / Sinc / Keiser /Hanning / Hamming / Blackman /Blackman-Harris/ Blackman-Nuttal / Nuttal/Keiser -Bessel/Sine Starting | |
RMS compressor | Threshold range: -10dBu~ +20dBu; Compression ratio range:2~32: 1; Soft and hard knee: 0~100% Attack time:0.1ms~1000ms; Release time: 10ms~15000ms Gain compensation:Maximum 12dB | |
Peak limiter | Threshold range: -10dBu~ +20dBu Attack time: 1ms~1000ms; Release time: 10ms~3000ms | |
Delay | The adjustable delay time of each input channel + output channel is 802ms, Step accuracy 0.0104ms (10.4us) | |
Audio | |||
Models | 2F6 | 4F8 | |
Input x Output | 2x6 | 4x8 | |
Input impedance | ＜10k Ohm balanced | ||
Output impedance | ＜100R Impedance balanced | ||
A/D dynamic range | 118dB | ||
D/A dynamic range | 118dB | ||
Maximum input level | +20dBu | ||
Maximum output level | +18dBu | ||
Total harmonic distortion | ≦0.003%(+4dBu 1kHz) | ||
Frequency response | 20Hz~20kHz | ||
Crosstalk | ≦-95dB | ||
SNR | ≧111dB (A weighting) | ||
Noise floor | ≦-91dBu (A weighting) | ||
Common Mode Rejection Ratio | 60dB | ||
Rs485 control port | 2 | ||
Network control port | 1 | ||
Puerto USB | N/A | 1 | |
Presets | 32 | ||
Dimensiones | ||
size | 483x44x207mm 1RU | |
Package size | 560x320x110(mm) | |
Net/Gross weight | 3.0 Kg / 3.5 Kg | |
